Needle Pressure Gauge

Get a Price/Quote

Needle Pressure Gauge Specification

Measuring Range
0~3000 psi

Automation Grade
Manual

Application
Industrial, Laboratory, Hydraulic and Pneumatic Systems

Power Supply
Not Required (Mechanical Gauge)

Test Range
0~3000 psi

Accuracy
+/-2% F.S.

Response Time
Instant

Resolution
5 psi

Gas Pressure
Upto 3000 psi

Max Height
115 mm (approx.)

Mounting Type
Panel / Direct Mount

Humidity
0~80% RH (Non-condensing)

Display Type
Analog (Mechanical Dial)

Temperature
-20C to 60C

Port Size
1/8 NPT (Standard)

Features
Robust construction, corrosion-resistant body, clear dial with color-coded zones, easy installation

Interface Type
Threaded Connection

Usage
Pressure measurement of liquids and gases

Capacity
3000 psi

Machine Weight
Approx. 260 g

Control Mode
Manual

Needle Pressure Gauge Trade Information

Main Export Market(s)
Asia

About Needle Pressure Gauge

We are one of the leading names in the industry, offering an excellent stock of Needle Pressure Gauge. Our highly skilled team wisely procures this gauge from renowned vendor present in market. Needle gauge is manufactured in strict tandem with industry standards using supreme materials. Needle Pressure Gauge is specifically designed to measure air pressure in blast and air hoses.

Features:

Precise results
Durable quality
Light weight
Measure air pressure in blast and air hoses.

Specification

Measuring Range	0-160 psi
Dimensions	130 x 55 x 26mm (5.12 x 2.16 x 1.02)
Weight	184g (6.49oz)

Durable and Reliable Construction

Crafted with a stainless steel case and acrylic glass window, this pressure gauge is engineered for long-lasting performance, even in harsh industrial settings. Its corrosion-resistant body and brass movement components ensure durability, while the aluminum pointer facilitates precise, clear measurements every time.

Versatile Applications Across Industries

This needle pressure gauge is ideal for monitoring pressures in air, gas, oil, water, and non-corrosive fluids. Its wide compatibility and accuracy make it suitable for industrial, laboratory, hydraulic, and pneumatic systems, supporting operational safety and efficiency in numerous applications.

Precise Measurement and Easy Installation

With a measuring range up to 3000 psi and accuracy of +/-2% F.S., this analog gauge offers detailed and color-coded pressure readings at a glance. The 1/8 NPT threaded port and bottom connection enable fast, hassle-free installation for both panel and direct mounting setups.

FAQs of Needle Pressure Gauge:

Q: How do I install the needle pressure gauge with a 63 mm dial diameter?

A: The gauge can be mounted either directly or on a panel using its threaded 1/8 NPT bottom connection. Ensure the mounting location is secure and suitable for accurate pressure measurement within your intended system, such as hydraulic or pneumatic setups.

Q: What types of fluids can I monitor with this pressure gauge?

A: This pressure gauge is compatible with air, gas, oil, water, and other non-corrosive fluids, making it versatile for a range of applications in industrial and laboratory environments.

Q: When is it appropriate to use this gauge instead of an electronic pressure sensor?

A: Use this gauge when you require a mechanical, power-free solution and need instant, reliable pressure readings, particularly in environments where electricity is unavailable or undesirable.

Q: Where should I position the gauge for optimal performance?

A: Install the gauge in a location that allows clear visibility of the dial, ensures easy access for inspection, and is protected from severe vibration or corrosive chemicals beyond its specified compatibility and IP44 ingress protection.

Q: What is the process for reading the pressure value on this analog dial?

A: Simply observe the position of the aluminum pointer on the color-coded, analog dial. The pressure in psi (up to 3000 psi) will be indicated directly, allowing you to monitor system status instantly.

Q: How does this gauge benefit industrial operations?

A: Its robust, corrosion-resistant design, high accuracy, and instant response help maintain safety and efficiency in industrial systems, reducing maintenance costs and equipment downtime due to its mechanical reliability.
